Section Draw Bench Machine

Name: Section Draw Bench Machine
Brand: NORTH INDIA MACHINE TOOLS
Price: 500000 INR
Availability: InStock

Price 500000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Section Draw Bench Machine Specification

Operating Temperature
Ambient to 45C

Model No
SDBM-100

Frame Type
Welded steel frame

Features
High load capacity, robust design, smooth operation, easy maintenance

Production Capacity
Up to 10 tons per shift

Connectivity Options
Optional Remote Monitoring

Noise Level
<80 dB

Drive
Chain / Gear Drive

Machine Type
Section Draw Bench

Power Rating
Three Phase

Cooling System
Water / Air Cooled

Accuracy
0.01 mm

Frequency
50 Hz

Voltage
380-440 V

Motor Power
7.5 - 20 HP

Control System
PLC based

Lubricating System
Centralized Automatic Lubrication

Product Type
Section Draw Bench Machine

Technology
Advanced Draw Bench Technology

Power Source
Electric

Operating Type
Semi-Automatic

Power
7.5 kW - 20 kW (depending on capacity)

Pressure
Up to 100 Tons

Surface Treatment
Painted / Powder Coated

Dimension (L*W*H)
Variable (as per machine design)

Weight (kg)
4500 - 12000 kg

Color
Industrial Blue & Silver

Usage & Applications
For drawing sections, bars, and tubes in steel plants and engineering industries

Finish
Industrial Grade Paint

Working Speed
Up to 10 m/min

Chain Type
High Strength Industrial Chain

Foundation
Grouted Base Required

Loading/Unloading
Manual or Powered Trolley Provided

Pulling Mechanism
Hydraulic or Mechanical

Main Shaft Diameter
Up to 150 mm

Draw Length
Up to 14 meters

Supply Phase
3 phase

Safety Standard
CE Marked / IS Standard

Material Handled
Steel, Alloy Steel, Copper, Aluminum Sections

Operator Interface
Digital HMI

Number of Rollers
2/3 Precision Rollers

Max Draw Force
Up to 1000 kN (varies with model)

Maintenance
Low Maintenance Design

About Section Draw Bench Machine

Unveil commanding performance with our Section Draw Bench Machine, an eminent solution highly popular in the industry for handling steel, alloy steel, copper, and aluminum sections. This inestimable machine offers a working speed up to 10 m/min and draws forces up to 1000 kN, boosting productivity in every deal and sale. Equipped with a digital HMI, low maintenance design, and dual/tri precision rollers, it delivers exceptional control, robust safety, and seamless operation. CE marked for unparalleled quality, this bench is the preferred choice for engineering and steel plants across India, balancing technology and industrial reliability.

Versatile Section Draw Bench Machine: Industrial Application & Advantages

The Section Draw Bench Machine is widely utilized in steel plants and engineering industries for shaping and drawing bars, tubes, and sections. Known for its popular application, it's used as a precision forming device, ensuring tight tolerances and quality finishes. Its advanced design offers significant advantages such as high load capacity, smooth hydraulic or mechanical operation, and commanding structural reliability. Operators benefit from efficient production runs and easy integration, making it a highly valued addition to any manufacturing setup.

Section Draw Bench Machine: Sample Policy, Certifications, Payment Terms & Shipment

Sample policies are tailored to meet client requirements, ensuring quality assurance before shipment. The machine is supplied with eminent certifications like CE and IS Standards, validating industry trust. Flexible payment terms are available to suit both domestic and international markets, ensuring seamless order completion. Our team coordinates with clients throughout the order and shipment process, delivering certainty and transparency at every stage for a hassle-free buying experience.

FAQ's of Section Draw Bench Machine:

Q: How does the Section Draw Bench Machine improve productivity in steel plants?

A: The machine boasts a commanding draw force and adaptable draw length, allowing for the efficient processing of multiple metals like steel, alloy steel, copper, and aluminum. Its advanced PLC-based control ensures accuracy (up to 0.01 mm) and consistent high production capacity of up to 10 tons per shift.

Q: What is the process for operating this draw bench machine?

A: Operation involves setting up the section or bar, selecting hydraulic or mechanical pulling mode, and configuring parameters through the digital HMI. Loading can be manual or powered trolley, while the entire drawing and unloading process is designed for operator ease and safety, requiring minimal supervision.

Q: Where is the Section Draw Bench Machine predominantly used?

A: This machine is commonly installed in steel plants and diverse engineering workshops, particularly where precise shaping of metal sections and tubes is required. Its robust structure allows it to be a popular choice in heavy-duty and continuous operation facilities.

Q: What are the benefits of the centralized automatic lubrication system?

A: This inestimable feature ensures all critical components receive consistent lubrication, minimizing maintenance needs, reducing wear, and extending the service life of the equipment, which is highly valued in commanding industrial environments.

Q: When can customers expect order completion and shipment?

A: Order completion timelines depend on customization and volume, but transparent updates and communication are provided from order processing through shipment. Delivery schedules are optimized for both domestic and international markets.
