Chain Type Draw Bench

Name: Chain Type Draw Bench
Brand: NORTH INDIA MACHINE TOOLS
Price: 500000 INR
Availability: InStock

Price 500000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Chain Type Draw Bench Specification

Features
Sturdy construction, Long service life, Smooth chain operation, Customizable length

Control System
Manual/Electrical Controls

Cooling System
Water/Oil Cooling optional

Connectivity Options
Standard Electrical Connections

Power Rating
Rated for heavy-duty operation

Model No
CTDB Series

Frame Type
Heavy-duty MS Fabricated Frame

Voltage
380-440 V

Accuracy
0.1 mm

Motor Power
7.5-15 HP

Production Capacity
2-8 Tons/Day

Machine Type
Chain Type Draw Bench

Drive
Chain Drive

Lubricating System
Centralized grease lubrication

Noise Level
80 dB

Frequency
50/60 Hz

Operating Temperature
Ambient to 40C

Product Type
Chain Type Draw Bench

Technology
Mechanical & Chain Driven

Power Source
Electric

Operating Type
Semi-Automatic

Power
5-20 kW (depending on model)

Pressure
Customizable as per requirement

Surface Treatment
Painted/MS/Coated

Dimension (L*W*H)
Variable as per capacity (e.g., 6000 x 1200 x 1300 mm)

Weight (kg)
3500 - 7000 kg

Color
Industrial Green or as required

Usage & Applications
Wire rod drawing, tube and pipe drawing, bar straightening

Trolley Movement
Motorized

Optional Attachments
Pneumatic Clamps, Extended Runway

Max Draw Force
Up to 60 Ton (model dependent)

Length of Draw
Up to 12 meters (customizable)

Installation Type
Floor Mounted

Material Handled
Carbon Steel, Stainless Steel, Non-Ferrous Metals

Main Shaft
Alloy Steel, Heat Treated

Automation Grade
Semi-automatic/Manual

Working Speed
0.3-1.5 m/min (adjustable)

Die Holder Type
Adjustable

Electrical Protection
IP54 Panel with MCB

Chain Type
High Precision Roller Chain

Operator Panel
Push button/Panel based

Safety Features
Overload protection, Emergency stop

About Chain Type Draw Bench

The Chain Type Draw Bench CTDB Series delivers unrivaled performance for wire rod, tube, and bar drawing across carbon steel, stainless steel, and non-ferrous metals. Its notable features include adjustable working speed (0.3-1.5 m/min), high-precision roller chains, heavy-duty MS fabricated frame, and a robust main shaft of heat-treated alloy steel. With safety at the forefront, the bench is equipped with overload protection and emergency stop systems. This spotlight machinery is now available at a reduced price, offering a prime purchase opportunity for manufacturers seeking long-lasting, efficient solutions.

Chain Type Draw Bench: Features and Applications

The Chain Type Draw Bench is engineered for Wire Rod Drawing, Tube and Pipe Drawing, and Bar Straightening. Highlighted by its adjustable die holder and customizable length, it supports various materials such as carbon steel, stainless steel, and non-ferrous metals. Its semi-automatic/manual operation and smooth chain drive make it a noteworthy choice for commercial production, ensuring longevity and sturdy construction for industrial demands.

Chain Type Draw Bench: Supply, Market, and Proposal

With significant supply ability across India's main domestic and export markets, our Chain Type Draw Bench delivers both quality and valuation in every transaction. We offer flexible sample policies tailored to your proposal amount for efficient decision-making. Customization and technical consultation are available to align with specific project requirements, supporting seamless integration and optimal performance for industrial applications.

FAQ's of Chain Type Draw Bench:

Q: How does the Chain Type Draw Bench enhance production efficiency?

A: The bench features adjustable working speeds, high-precision roller chains, and customizable lengths, enabling smooth operation and efficient material handling for higher daily output.

Q: What materials can be processed using this draw bench?

A: It is suitable for carbon steel, stainless steel, and various non-ferrous metals, making it versatile for multiple drawing applications.

Q: When is it ideal to use a semi-automatic or manual operation mode?

A: Semi-automatic mode is best for continuous processes, while manual operation offers greater control for precise tasks or short production runs.

Q: Where is the Chain Type Draw Bench typically installed?

A: The bench is floor mounted and commonly installed in industrial plants specializing in metalworking, wire, tube, or pipe processing.

Q: What safety features are incorporated in the machine?

A: It is equipped with overload protection and an emergency stop, enhancing operator safety during daily operations.

Q: How customizable are the dimensions and pressure settings?

A: Both the length of draw and pressure specifications can be tailored to individual project requirements, providing flexibility and suitability for diverse industrial applications.
