Bright Bar Drawing Machine

Name: Bright Bar Drawing Machine
Brand: NORTH INDIA MACHINE TOOLS
Price: 500000.0 INR
Availability: InStock

Price 500000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Bright Bar Drawing Machine Specification

Noise Level
<70 dB db

Operating Temperature
5C - 45C Celsius (oC)

Machine Type
Bar Drawing

Drive
Chain & Gear Drive

Accuracy
0.05 mm mm

Cooling System
Water Cooling

Model No
BBDM-120

Frequency
50 Hz Hertz (HZ)

Power Rating
10 HP

Production Capacity
3-6 Ton/Day Ton

Frame Type
Heavy Duty Welded Frame

Features
High rigidity frame, Energy efficient, Corrosion resistant, Easy operation and maintenance

Connectivity Options
Optional Remote Monitoring

Motor Power
7.5 kW Volt-Ampere (VA)

Lubricating System
Centralized

Voltage
380-415V Volt (v)

Country Of Origin
India

Product Type
Other

Technology
Other

Power Source
Other

Operating Type
Automatic

Power
7.5 kW Volt (v)

Pressure
80-120 Ton (Adjustable) kgf/cm2

Surface Treatment
Other

Dimension (L*W*H)
5100 x 1350 x 1200 mm Meter (m)

Weight (kg)
3200 kg Kilograms (kg)

Color
Green & Yellow

Usage & Applications
Used for producing bright steel bars from raw material; suitable for construction, auto parts, and fabrication industries

Bar Length Range
2 to 6 meters

Installation
On-site commissioning available

Roller Material
Alloy Steel

Main Shaft Speed
1200 rpm

Safety
Emergency stop, Overload protection

Minimum Bar Diameter
6 mm

Working Speed
12-25 m/min

Operator Required
1

Maximum Bar Diameter
32 mm

Input Material
Mild Steel, Carbon Steel, Alloy Steel

Bright Bar Drawing Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
6 Pieces Per Year

Delivery Time
60 Days

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Bright Bar Drawing Machine

Discover the Bright Bar Drawing Machine-an extraordinary fusion of top-tier engineering and customizable features. Experience remarkable price cuts with our dynamic offerings, supported by an impressive production capacity of 3-6 tons per day. Engineered for lofty industrial ambitions, it supports a bar diameter range of 6 to 32 mm and offers a high shaft speed of 1200 rpm. Equipped with a robust cold drawing technology, a heavy-duty welded frame, automatic operation, and state-of-the-art PLC control, this machine ensures precision (0.05 mm), safety, and efficiency. Its energy-efficient design, advanced cooling, and centralized lubrication deliver optimal performance in demanding applications. Customizations and installation support available.

Specialized Applications and Versatility of the Bright Bar Drawing Machine

The Bright Bar Drawing Machine stands as a versatile solution for both highly specialized and general industrial uses. Ideal for transforming raw steel into premium bright bars, it finds application in construction, automotive components, and fabrication industries. This machine is adept at working with a variety of input materials-mild steel, carbon steel, and alloy steel-across bar lengths from 2 to 6 meters. Its polished, corrosion-resistant surface treatment ensures reliability in demanding environments and across multiple industries.

Supply Capacity, Transaction Process, and Certifications for Bright Bar Drawing Machine

With an impressive daily rate of 3-6 tons, the Bright Bar Drawing Machine is available for rapid supply across India. We facilitate smooth packaging and logistics, ensuring machines arrive safely and on schedule. Payment terms are crafted for customer convenience and flexibility. Each unit complies with requisite certifications, attesting to its safety and quality. Our logistics team provides on-site commissioning, and we support clients with clear documentation, enhancing the ease of procurement and machine setup.

FAQ's of Bright Bar Drawing Machine:

Q: How is the Bright Bar Drawing Machine installed and commissioned?

A: The machine is installed at your facility with on-site commissioning support from our technical team, ensuring proper setup and training for smooth operation.

Q: What safety features are integrated into the machine?

A: Safety is paramount; the machine includes an emergency stop, overload protection, and operates at low noise levels (<70 dB) to ensure operator well-being.

Q: What types of materials can be processed with this machine?

A: You can process mild steel, carbon steel, and alloy steel, making the machine suitable for diverse industries requiring strong, high-grade bars.

Q: Where can the Bright Bar Drawing Machine be effectively used?

A: It's ideal for construction sites, auto parts manufacturing, and fabrication workshops that demand precision and consistent output for steel bars.

Q: What are the main benefits of the cold drawing technology used?

A: Cold drawing technology enhances the mechanical properties, surface finish, and precise dimensional accuracy (up to 0.05 mm) in the produced bright steel bars.
